Application & Installation:

They are recommended for pumping clean water without abrassive particles and liquid are chemically non-aggressive to the materials of which the pump is made. They are suitable for domestic use and in particular for delivering water in combination small automatic pressure sets,as well as for irrigation.
The pumps shall be installed in enclosed places, or at least protected against inclement.

Operating Conditons:

Liquid temperature up to 60°C
Ambient temperature up to 40°C
Total suction lift up to 9m
Continuous duty

Component Construction：

Pump body: Cast iron
Pump support: Cast iron
Motor housing: Aluminum
Impeller: Brass
Motor shaft: Carbon steel, AISI304 SS if request
Mechanical seal: Ceramic/Graphite

Motor：

Two-pole induction motor(n=2850 r.p.m)
Insulation Class B
Protection IP44
Continuous service S1
Thermal protector
Single-phase 220V/50Hz, 60Hz if request
